4L4122 LITE Liner Silikon SkinTex 3 L SOFT Cushion

Item number: 4L4122

Category: All products

Size

Amputation level: BK
Connector: Cushion
Fabric Type: SkinTex without seam
Liner Thickness: 6 mm
Liner Profile: Uniform
Material Liner: Silicone Gel
Matrix: with outside matrix
Mobility grade: mobility class: 1-3

There are variations of this item. Please select the variation you wish.

Description

4L4122 LITE Liner Silikon SkinTex 3 L SOFT Cushion

Mobility class: 1-3
for BK stumps
Connector: Cushion (without distal connector)

Properties:

  • made from medical grade* silicone gel
  • seamless fabric cover
  • length approx. 38 cm
  • integrated outside matrix



  • standard with approx. 10 cm matrix
  • high comfort by using approx. 2,5 mm ComfortSil Silicone Gel
  • perfect pressure distribution
  • textile fabric for easy donning
  • reduced pistoning by the matrix



Article number Matrix length  Distal Circumference
4L4122-10-18 approx. 10 cm 18 cm
4L4122-10-20 approx. 10 cm  20 cm
4L4122-10-21 approx. 10 cm  21 cm
4L4122-10-22 approx. 10 cm  22 cm
4L4122-10-23,5 approx. 10 cm  23,5 cm
4L4122-10-25 approx. 10 cm  25 cm
4L4122-10-26,5 approx. 10 cm  26,5 cm
4L4122-10-28 approx. 10 cm  28 cm
4L4122-10-30 approx. 10 cm  30 cm
4L4122-10-32 approx. 10 cm  32 cm
4L4122-10-34 approx. 10 cm  34 cm
4L4122-10-36 approx. 10 cm  36 cm
4L4122-10-38 approx. 10 cm  38 cm
4L4122-10-40 approx. 10 cm  40 cm
4L4122-10-42 approx. 10 cm  42 cm
4L4122-10-45 approx. 10 cm  45 cm



Sizing

 How to choose the correct liner size
a) Measure the circumference of the residual limb at 4 cm from the distal end.
b) Choose the liner size corresponding to this measurement or the next smaller size, respectively.
c) Do not choose a liner whose size exceeds the measurement taken.
d) Never reduce by more than one liner size in order to avoid unnecessarily high compression.

Important:
In locking liners, a matrix with 10 cm length is integrated as a standard.This matrix should end below the head of the fibula and must not exceed it, as this could result in problems during knee flexion.
